Page 6 SKU 96933 For technical questions, please call 1-800-444-3353.
BulB replaceMent
wear anSi-approved safety goggles and heavy-duty work
gloves when replacing the bulb.
Make sure the burned-out bulb has cooled completely. 1.
Gently pry off a lens covering the burned out bulb using plastic pry tools (not 2.
included) to prevent damage.
Press the burned-out bulb into the socket slightly and rotate it counterclockwise
3.
to release it. Make a note of the orientation of the pin’s as one is located lower
than the others. Remove the burned-out bulb.
Insert a new 12V/21/5W bulb into the socket (note pin orientations) and while
4.
pushing it down turn it clockwise to secure.
Gently snap the lens back in place, and test the lights to ensure proper opera-
5.
tion before use.
caution
partS liSt
part description Qty
1 Amber Front Lens 2
2 Red Rear Lens 2
3 Bracket 2
4 Bulb 2
5 Socket 2
6 Threaded Shaft 2
7 Shell 2
8 Spring Washer 2
9 Flat Washer 2
10 Ground Terminal 2
11 Nut 2
12 Screw 2
part description Qty
13 Cover 2
14 Magnet 2
15 Nut 2
16 Screw 8
17 Power Cord 1
18 “Trailer” 4-way Flat Connector 1
19 Left-Right Cord 1
20 Bulb Wire 4
21 Wire Splices 4
22 Wiring Pigtail 1
23 “Trunk” 4-way Flat Connector 1
24 Protective Label 2
record product’s Serial number here:
note: If product has no serial number, record month and year of purchase instead.
note: Some parts are listed and shown for illustration purposes only, and are not
available individually as replacement parts.
After towing, disconnect “Trailer” Connector, remove tow lights from towed 8.
vehicle, clean with a moist cloth, and store in dry location out of reach of
children. Do not drag the magnetic bases to disconnect, as they may scratch
the body paint. Push to tilt then remove.
