7
Consumer Support
Troubleshooting T
ips
Operating Instructions
Safety Instructions
Installation Instructions
Non-Adjustable Shelves on the Door
Detachable shelves deepen and enclose
fixed door shelves, providing more storage
room and greater storage flexibility.
To remove: Lift the shelf straight up then
pull out.
To replace: Engage the shelf extender in
the molded supports on the door and push
down. It will lock in place.
Freezer Tilt Out Bin (on some models)
Push the button as you tilt out the bin.
To remove: Hold the sides of the bin and lift
it straight up, then pull out.
To replace: Engage the ends of the bin in
the molded supports on the door and push
down. It will lock in place.
NOTE: Do not overload the bin.
Button
www.Hotpoint.com
Adjustable Bins on the Door
Adjustable bins can easily be carried from
refrigerator to work area.
To remove: Lift bin straight up, then pull out.
To replace or relocate: Engage the bin in the
molded supports of the door, and push
down. Bin will lock in place.
The snugger helps prevent tipping, spilling
or sliding of small items stored on the door
shelf. Grip the finger hold near the rear of
the snugger and move it to fit your needs.
Snugger
Finger hold
Slide-Out Spillproof Shelf
(on some models)
The slide-out spillproof shelf allows you
to reach items stored behind others. The
special edges are designed to help prevent
spills from dripping to lower shelves.
To remove:
Remove all items from shelf.
Slide the shelf out until it stops.
Lift the front edge of the shelf until the
tabs are above the shelf frame.
Continue pulling the shelf forward until
it can be lifted out and removed.
To replace:
Place the rear of the shelf on the shelf
frame just behind the front bar.
Slide the shelf back until the tabs are
above the openings.
Lower the shelf so that the tabs go into
the openings, then slide the shelf all the
way in.
Make sure that the shelf sits flat after reinstallation
and doesn’t move freely from side to side.
Make sure you push the shelves all the way in
before you close the door.
Tab
Opening
Front bar
