- 27 -
4.4 Link Status
From the “Link Status” option, you can view all the information of the network you are connecting to. You
can use this tool in while at the same time repositioning the Hi-Gain antenna to find the optimal location for
antenna placement.
Parameter Description
Status Displays the SSID and MAC ID of the network the adapter is
connected to.
Current Channel Display the number of the radio channel and the frequency used
for the networking.
Parameter Description
Link Speed Display the transmission and receive rate of the network. The
maximum transmission rate is 54Mbps.
Throughput (Kbits/sec) Display the speed of data transmitted and received.
Link Quality This bar indicates the quality of the link. The higher the
percentage, the better the quality.
dBm If you want to know the signal strength in the unit of dBm, select
this check box.
Signal Strength This bar shows the signal strength level. The higher percentage
