7
English
ASSEMBLY OF STORAGE COMPARTMENT
(WDNSC145 Only)
BACK
PANEL
SIDE
PANELS
BASE
PANEL
TOP
PANEL
FORELOCK FRONT
PANEL
MIDDLE
PANEL
1 2 3
4 5
6
SCREWS
SCREWS
FORELOCK
1. As shown in fig. 1 and fig. 2, attach the side panels to the back panel.
2. Secure the base to the upper section with the provided screws.
3. Place the front panel on the base panel. Make sure that the hole on bottom left
of the door is aligned with the forelock.
4. Attach the top panel with the provided screws as shown, making sure that the
forelock is properly in place on the upper left side of the door and the top panel
is aligned with the forelock.
5. Place the middle panel inside the storage compartment as shown. The water
dispenser can now be set on the unit.
