17
This section describes the hardware installation procedures for the HNC300 and HNC320G.
HNC300
Connect an Ethernet Cable
Connect an Ethernet cable to the Ethernet cable port located on the rear panel of the camera, and attach the other end to
the network.
Attach the External Power Supply
Attach the external power supply to the DC power input connector located on the rear panel of the camera. The input
connector is labeled “DC 5V”. Connect it to your local power supply.
Note:
Confirm that the device is receiving power by making sure that the “Power” LED is illuminated.
10/100 Ethernet
DC 5V
Reset
10/100 Ethernet
DC 5V
Reset
