PARTS LIST

ITEM#

DESCRIPTION

QTY

ITEM#

DESCRIPTION

QTY

1

Adjustment Screw

1

15

Bushing

1

2

Grease Cap

1

16

Gear

2

3

Rotating Support

1

17

Shaft I

1

4

Adjustment Knob

2

18

Shaft II

1

5

Left Stand

1

19

Handle

1

6

Bushing

1

20

Nut M10

1

7

Flat Key 4x8

2

21

Handle Grip

1

8

Shaft III

1

22

Bolt M10x110

1

9

Handle Bushing

1

23

Pin

2

10

Right Stand

1

24

Adjustment Knob

2

11

Shaft Bushing

1

25

Base

1

12

Washer 6

1

26

Washer 10

4

13

Spring Washer 6

1

27

Spring Washer 10

4

14

Screw M6x16

1

28

Bolt M10x20

4

29

Bolt M6x6

1
