LIST PARTS MAINFRAME LOWER
1 AXLE FRONT WELD ASSY 560008 1
2 BAR SPRING TENSION 560037 1
3 BEARING 6001-2RS 411027 2
4 BEARING FRONT AXLE 410069 2
5 BEARING HOUSING 219102 2
6 BELT VARIATOR 520 411024 2
7 BOLT CENTRE BBC 343029 1
8 BRACKET CABLE HY412003 1
9 BRACKET CONN ROD 560029 1
10 BUSH DIA 6.3*DIA 9.5*7 340154 1
11 BUSH PIVOT 411031 1
12 PULLEY 51MM PCD 111-0634 1
13 CHAIN 40 PITCHES 3/8" INC LINK" 411016 1
14 CLAMP UNDERDECK 560027 1
15 ROD-CONNECTING W/A 560028 1
16 COVER DRIVE 411013 1
17 CUTTERBAR BBC 22" 343034 1
18 SPRING CABLE ANCHOR 111-0527 1
19 ROLLER FREEWHEEL 340150 2
20 WARNER BBC 5915-24 485007 1
21 FRONT_FINS 560014 1
22 GEARBOX 411002 1
23 GRIP FIX EXT 5/16" 04020 1
24 HOUSING PIVOT BEARING - LH 410048 2
25 CAP HUB 219143 2
26 KEY WOODRUFF No 505 1662 1
27 KNOB HOC 480134 1
28 HOC LEVER W/A 560046 1
29 LEVER VARIABLE PULLEY 411014 1
30 LOCKNUT 340163 1
31 NUT M6 LUG 410076 4
32 MAINFRAME 560010V 1
33 NUT M6 09544 2
34 NUT M8 NYL INSERT T TYPE 09441 1
35 NUT UNF 1/2" NYLOC EXT THIN5/16" HY4486 2
36 SPACER NYLON 55*41.5*1 BLACK 340149 1
37 OILITE BUSH ROLLER 340129 2
38 PIN ROLL DIA 3/16*3/4 03997 1
39 PIN SELLOC SPRING HY03354 1
40 PLATE SECURING 219037 1
41 FRMAE REAR ROLLER W/A HY560002 1
42 ROLLER SHELL ASSEMBLY 560031W 2
43 NIPPLE SPLIT 510118 1
44 SCREW TAPTITE M6*16 09365 35
45 SCREW TAPTITE M6*16 C/SK POZI 09545 4
46 SCREW TAPTITE M6*20 W/HD 09575 3
47 SCREW TAPTITE M8*25 HEX W/HD 09787 1
48 SETSCREW M6*25 09364 2
1.34
ITEM NO.
QTY.
563 DESCRIPTION PART NO. ITEM NOTE
