1 CLIP GRASSBAG FLAP 111-0458 2
2 CONNECTING ROD 111-0187 1
3 BAT TE RY CO V E R 5 6 0 0 1 5 1
4 BOLT HANDLEBAR M8*45 226024 2
5 C A B L E B B C 111- 0 1 9 2 1
6 GUIDE CABLE 410037 4
7 CABLE_CLUTCH V/S 560038 1
8 CAP FOR M8 NUT BLACK 234051 2
9 HANDLEBAR CLAMP PLATE 340028 2
10 COVER_GRASSBAG 560021 1
11 DEFLECTOR 111-0633 1
12 ENGINE B&S INTEK EDGE 55 OHV 563019 1
13 BBC CONTROL LEVER 340179 1
14 FRAME_GRASSBAG 560023W 1
15 FABRIC GRASSBAG 560022 1
16 GUIDE_ROPE 305093 1
17 HANDLEBAR LOWER 560009W 2
18 HANDLEBAR UPPER MOULDED 111-0519 1
19 LEVER CLUTCH 306094W 1
20 BOLT COACH M8 x 40 GRADE 8.8 09379 2
21 NUT M6 NYLOC ‘T’ TYPE 09438 2
22 NUT M8 NYL INSERT T TYPE 09441 2
23 PIN PIVOT 340182 2
24 RATCHET PLATE HOC 560018 1
25 CONTROL LEVER MOULDING 111-0185 1
26 ROD DEFLECTOR 560017 1
27 SCREW TAPTITE M6*16 09365 4
28 TOP MOULDING CONTROL 111-0183 1
29 SCREW TAPTITE UNC 3/8"*1 1/4" 09349 1
30 SCREW 06*20 PT PAN FLANGE 09687 2
31 SETSCREW M6x55 POSI PAN Z&P 09780 2
32 THROTTLE CONTROL 111-0512 1
33 SPRING DEFLECTOR 410030 1
34 CABLE VARIATOR 560039 1
35 KNOB M8 HANDWHEEL 480088 2
36 WASHER NYLON 19*11*1.6 09688 2
37 ACTUATOR MOULDING CONTROL 111-0186 1
38 ANCHOR MOULDING CONTROL 111-0184 1
39 P L U G T U B E 7 / 8 *1 6 G 3 0 0 1 60 2
40 DECAL HAYTER ROYAL WARRANT 410087 1
41 DECAL SERIAL NUMBER -------- 1
42 DECAL ENGINE 111-0744 1
43 STARLOCK PUSH-ON FASTENER 5MM 111-0718 1
44 CABLE TIE HY3966 1
45 DECAL HEIGHT OF CUT 320006 1
46 GRASSBAG ASSEMBLY 560020 1 INCLUDES 1,10,14,15
47 D E C A L BB C 111- 0 7 4 5 1
48 PLAIN WASHER M6*12*1.6 09472 1
49 DECAL CAUTION 111-0083 1
50 NUT M6 NYLOC P TYPE 09544 1
51 BASE MOULDING CONTROL 111-0182 1
52 SCREW 10*3/4 S TAP 70-11-012 3
53 GRIP FIX EXT 5/16" 04020 2
LIST PARTS MAINFRAME UPPER
1.32
ITEM NO.
QTY.
563 DESCRIPTION PART NO. ITEM NOTE
