3
Shertech Operating Instructions, Performance,
Specifications and Parts Manual
Bronze Models GCBN2V, GCBN3V, GCBN22V and GCBN33V
Cast Iron Models GCCV2V, GCCV3V, GCCV22V and GCCV33V
Form L-4083 (1/06)
Performance
GPM Pumping 10 Wt. Oil at 70° F (500 SSU)
Bronze Cast Iron Port Motor RPM Max. Input Suction Free Flow 20 PSI 40 PSI 60 PSI 80 PSI 100 PSI
Models Models Size* HP Torque in.-lbs. Lift** GPM GPM GPM GPM GPM GPM
Models with Motors Equipped
GCBN22V GCCV22V 1/4 1/3 1725 45 3.2 2.2 2.1 2.0 1.8 1.7 1.6
GCBN33V GCCV33V 3/8 1/2 1725 45 3.6 4.4 4.3 4.2 4 3.8 3.6
Models without Motors Suggested
GCBN2V GCCV2V 1/4 1/3*** 1725 45 3.2 2.2 2.1 2.0 1.8 1.7 1.6
GCBN3V GCCV3V 3/8 1/2*** 1725 45 3.6 4.4 4.3 4.2 4 3.8 3.6
Test data taken on SAE 10 wt. oil at 70° F (500 SSU).
Performance in water will decrease by about 10%, and HP required will also be reduced by 10%. (Don’t use water with Cast Iron.)
Pump performance when pump is new. As pump wears, the performance will decrease.
(*) NPT inlet and outlet (in inches).
(**) Suction lift requires wetted gears and primed seal chamber.
(***) Motor not provided.
NOTES: Pumps with motors are HP rated to handle up to 500 SSU at 100 PSI and specific gravity of 1.0.
Max. PSI = 100
Max. Viscosity = 500 SSU
Max. RPM = 1725
Max. Specific Gravity = 1.1 at 100 PSI, up to 1.6 at lower PSI & viscosity.
Max. Input Torque = See chart above.
Reverse Rotation = Pumps are equipped with pressure relief valves and can be run in reverse rotation; however, pressure relief valve will not
function when pump is reversed unless pump relief valve cover is rotated 180°.
The pump relationship between volume (GPM), pressure (PSI), speed (RPM) and horsepower is shown on performance chart in Shertech Motor
Manual form L-4082. When pumping a more viscous liquid, a slower speed, a larger pipe size pump, and possibly a larger motor should be selected.
Manufacturer reserves the right to change performance without notification.
