Pole identification mark – Huffy Fitness Equipment User Manual
Page 9
03/03
P/N 211689A
9
IMPORTANT! Holes in top (1) and bottom pole (3) sections MUST align to
correctly position elevator system toward playing surface.
While maintaining alignment, bounce assembly and lower section (3) together
as shown until they no longer move toward pole identification mark.
NOTE: Pole sections should have a 3-1/2" (9 cm) minimum overlap.
1
2
3
3.
WOOD SCRAP
POLE
IDENTIFICATION
MARK
