IMPORTANT! Bounce pole top (1) and middle section (2)
together as shown until they no longer move toward
taped reference mark. Upright assembly. NOTE: Pole
sections should have a 3-1/2" (9 cm) minimum overlap.
SECTION A: ASSEMBLE THE POLES
2.
1.
Wood Scrap
2
1
5"
(13 cm)
MIDDLE
TOP
5"
(13 cm)
BOTTOM
1
3
2
Correctly identify each pole
section. Mark pole sections
with tape as shown.
TAPE
BEFORE YOU START!
Test fit large bolts into large holes of elevator tubes, backboard brackets and triangle
plates. Rock the bolt in a circular motion to ream out any possible excess paint.
