Specifications – Humminbird TCR ID-1 User Manual
Page 25
SPECIFICATIONS
Operating Frequency
455KHz
Power Requirement
12 volts
Power Cable Length
11½’
Sensor (standard)
SHS-6-16 High-Definition, high-speed
Sensor Cone Angle
16 degrees
Sensor Cable Length
20’
Depth Ranges
0-15’, 0-30’, 0-60’, 0-120’
Zoom Ranges
7½’, 15’
Mounting (standard)
All-in-One Mounting & Connector System
Unit Construction
High-impact polycarbonate case
Dimensions
6 ½” W X 6 ¾”H X 1 ½”D
Display
liquid crystal
Viewing Area
3” W X 4" H
Matrix Configuration
48 x 75 pixels
