49
English
USEFUL INFORMATION
Features:
• New Easy-to-Use On-Screen Menu Control (3 Language)
• Film Mode Processing with 3:2 & 2:2 pull down
•
Integrated ATSC Tuner
• Adjustable Color Temperature ( This is only for PC mode.)
• PIP / POP
• Picture Enhancement
• Input Signal Identification
• HDMI (High Definition Multimedia Interface)(High Bandwidth
Digital Content Protection V1.1 Compatible)
Video:
• 1366 x 768 Display Resolution
• Wide Viewing Angle: More than 160°
• 2 Color Temperature Presets: High / Low
• Multiple Screen Fill Modes (4:3 Standard, 4:3 Expanded, 4:3
Zoom1, 4:3 Zoom2, 16:9 Standard, 16:9 Zoom)
1
• 3D Y/C Comb Filter
• Picture Modes (Natural, Cinema, Dynamic and Game)
• Computer Display: VGA, SVGA, XGA, WXGA
• HDMI Display: VGA, 480i, 480P, 720P, 1080i
Inputs:
• Antenna input impedance . . . . . . . . . . . . . . . . . . . . . .75
Ω
• Channel coverage . . . . . . . . . . . . . . . . . . . . . . . . . . . . .191ch.
VHF-Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 ~ 13
UHF-Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 ~ 69
CATV Mid Band . . . . . . . . . . . . . . . . . . . . . . . . . . .A-5 ~ A-1
. . . . . . . . . . . . . . . . . . . . . . . . . . . A-I
Super Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . J-W
Hyper Band . . . . . . . . . . . . . . . . . . . . . . . . . . . W+1 - W+28
Ultra Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . .W+29 - W+94
• Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.0Vp-p, 75
Ω
• S-Video
Luminance (Y) . . . . . . . . . . . . . . . . . . . . . .1.0Vp-p, 75
Ω
Chrominance (C) . . . . . . . . . . . . . . . . . .0.286Vp-p, 75 Ω
• Component Video
Luminance (Y) . . . . . . . . . . . . . . . . . . . . . .1.0Vp-p, 75
Ω
Chrominance (P
B
/P
R
) . . . . . . . . . . . . . . . .0.7Vp-p, 75 Ω
• Audio input Impedance . . . . . . . . . . . . . . . . . . . . . . 47k Ω
• Average input level . . . . . . . . . . . . . . . . . . . . . . . . .470mVrms
• RGB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.7Vp-p, 75
Ω
• HDMI . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . .. .(19 PIN)
Outputs:
• Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.0Vp-p. 75
Ω
• Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . .470mVrms, 1k Ω
• Head phone
Audio:
• Mono / Stereo / SAP
• SRS WOW
•10W+10W
• Mute
Supplied Accessories:
• Remote control
• Batteries
• Power Cable
• User’s Guide
• Easy Graphic Guide
• Warranty Card
• D-Sub Cable
• S-Video Cable
• AV Cable
• Cleaning cloth
• Cable ties
Optional Accessory:
• Wall mount
INPUTS/OUTPUTS
• Component Y, P
B
, P
R
........................................................ x 2
• RGB: Analog Input ............................................................ x 1
•
HDMI Input ........................................................................ x 1
• Composite Video............................................................... x 2
• S-Video.............................................................................. x 2
• Antenna (RF) Inputs.......................................................... x 2
- NTSC
- ATSC
• Audio Input ....................................................................... x 5
• Audio Output ..................................................................... x 1
• Video Output………………………………………………......x 1
• S-Video Output…………………………..…………………....x 1
• Subwoofer Output ............................................................. x 1
SPECIFICATIONS
• Multi-Scanning: .............................32-70kHz (h), 50-76Hz (v)
• Pixel Pitch .............................0.4215mm x 0.1405mm x RGB
• FCC class: .............................................B for Consumer Use
• Power Input: ..................................................AC 120V, 60Hz
• Power Consumption: ..................................
32HDL52A:150W
…............................... 37HDL52A:170W
at standby .....................................................................<1W
•Operating temperature:………………………………35ﾟC max
DIMENSIONS
32HDL52A:
• Width:812.5 mm
• Height:664 mm (with stand);583.5mm (without stand)
• Depth: 350mm (with stand);113.5 mm (without stand)
• Weight:27.8Kg (with stand);22 Kg (without stand)
37HDL52A:
• Width:940 mm
• Height:736 mm (with stand);657 mm (without stand)
• Depth:350mm (with stand);120 mm (without stand)
• Weight:32.8Kg (with stand);27 Kg (without stand)
Screen mode availability varies by input format
HDTV LCD TVs display HDTV when combined with an HDTV Tuner and Source.
All specifications, weights, and dimensions are subject to change without prior
notice. Please access www.hitachi.com/tv for detailed specifications and
dimensions for custom installations.
UltraVision Digital is a registered trademark of Hitachi Home Electronics
(America), Inc.
WOW, SRS and the symbol are trademarks of SRS Labs, Inc. WOW
technology is incorporated under license from SRS Labs, Inc.
HDMI, the HDMI logo and High-Definition Multimedia
Interface are trademarks or registered trademarks of
HDMI Licensing LLC.
