English

TURNTABLE INSTALLATION
a. Never place the glass tray upside down. The glass tray should never be restricted.
b. Both glass tray and turntable ring assembly must always be used during cooking.
c. All food and containers of food are always placed on the glass tray for cooking.
d. If glass tray or turntable ring assembly cracks or breaks, contact your nearest

authorized service center.

COUNTERTOP INSTALLATION
Remove all packing material and accessories. Examine the oven for any damage
such as dents or broken door. Do not install if oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not remove the light brown Mica

cover that is attached to the oven cavity to protect the magnetron.

INSTALLATION
1. Select a level surface that provide enough open space for the

intake and/or outlet vents.
A minimum clearance of 3.0 inches (7.5cm) is
required between the oven and any adjacent walls.
One side must be open.

(1) Leave a minimum clearance of 12 inches (30cm) above

the oven.

(2) Do not remove the legs from the bottom of the oven.
(3) Blocking the intake and/or outlet openings can damage

the oven.

(4) Place the oven as far away from radios and TV as

possible. Operation of microwave oven may cause
interference to your radio or TV reception.

2. Plug your oven into a standard household outlet. Be sure the voltage and the frequency is the same as the voltage

and the frequency on the rating label.

WARNING: Do not install oven over a range cooktop or other heat-producing appliance. If installed near or over a heat

source, the oven could be damaged and the warranty would be void.

The accessible surface may be hot during operation.

3.0 inch(7.5cm)

12 inch(30cm)

OPEN

Hub (underside)

Glass tray

Turntable shaft

Turntable ring
assembly
