Hawking Technology Hawking Hi-Gain Wireless USB Network Dish Adapter 300N - Manual (Page 6)

HWUN3
Step 1 - Run the Setup Wizard
Step 2 - Plug in the Wireless-N USB Adapter
Step 3 - Find your Wireless Network
Hi-Gain TM Wireless-N Network USB Adapter
with Upgradable Antennas
Specifications are subjet to change without notice. ©2007 Hawking Technologies, Inc. All Rights Reserved.
HAWKING TECHNOLOGIES, INC
USA: Irvine, California
Sales: 888.662.8828 or 949.790.0800 Fax: 949.790.0880
Email: [email protected] Email: [email protected]
EUROPE: Rotterdam, The Netherlands
Sales: 31-10-245-1600 Fax: 31-(0)10-245 1616
Email: [email protected] Email: [email protected]
RELATED PRODUCTS
HWDN1
HWRN1
HI-GAIN RANGE EXTENDING PRODUCTS
HAI7SIP
HAI7MD
HAI15SC
HAO9SIP
HAO9SDP
HAO14SDP
HAO15SIP
Hi-Gain USB Wireless-300N Network
Dish Adapter
Hi-Gain Wireless-300N Router
Hi-Gain 7dBi Omni-Directional Antenna
Hi-Gain 7dBi Directional Antenna
Hi-Gain 15dBi Corner Antenna
Hi-Gain 9dBi Outdoor/Indoor
Omni-Directional Antenna Kit
Hi-Gain 9dBi Outdoor/Indoor
Directional Antenna Kit
Hi-Gain 14dBi Outdoor/Indoor
Directional Antenna Kit
Hi-Gain 15dBi Outdoor/Indoor
Omni-Directional Antenna Kit
EXTEND YOUR WIRELESS RANGE
WIRELESS NETWORK DIAGRAM
READY, NETWORK & GO!
It is easy to install & easy to use.
SPECIFICATIONS
Network Specifications:
Š Windows 2000/XP/Vista
Š IEEE 802.11 b/g/n
Š Security: WEP 64, 128, 152bit WPA
(PSK, TKIP), WPA2 (AES)
Electrical Properties
Š Frequency: 2.4~2.4835 Ghz
Š Operating Voltage: 5V
Š LED indicator:
Solid Green & blinking mode
Mechanical Properties
Š Connector: USB 2.0/1.1
Material Properties
Š Color: White
Š Dimensions
10(H) x 28(W) x 89.6(D)mm.
Š Weight: 1.3 oz
Warranty
Š 1 year
NETWORK DIAGRAM
Print Server Printer
Wireless-N Router and/or
Internet Modem
Mac or PC
Desktop
Mac or PC Laptop
HWUN3 with Hawking’s Hi-Gain Indoor Antennas
Wireless-N Router
HAO9SIP
Hi-Gain 9dBi
Omni-Directional
Outdoor Antenna with
Wirless-N Router
HAO9SDP
Hi-Gain 9dBi Outdoor Directional
Antenna Connected to Laptop with the
Hawking HWUN3 USB Adapter
Desktop with HWUN3 USB Adapter
plus an HAI7SIP Omni-directional
Antenna
Laptop with HWUN3 USB Adapter
plus a HAI7MD Directional Antenna
HWUN3 with Hawking’s Hi-Gain Outdoor Antennas
EXTEND YOUR WIRELESS RANGE
with Hawking Hi-Gain™ Antennas
Extended Range
