16
Fig. 2
4. SET UP
1) If mounting unit on top of a storage bin, unpack the storage bin, and attach the four adjust-
able legs provided (bin accessory) to the bottom of the storage bin. If mounting unit on top
of a dispenser, follow the dispenser set-up procedure.
2) Position the Storage Bin/Dispenser Unit in the selected permanent position.
3) Place the icemaker on the top of the Storage Bin/Dispenser Unit.
4) Secure the icemaker to the Storage Bin/Dispenser Unit, by using the two mounting
brackets and the bolts provided. See Fig. 2.
5) Level the icemaker and storage bin/dispenser unit in both the left-to-right and front-to-rear
directions. Adjust the storage bin/dispenser unit legs to make the icemaker level.
6) Replace the panels in their correct positions.
Icemaker
Mounting
Bolt
Bin
Icemaker
Mounting
Bolt
Dispenser
