Parts list – Hayter Mowers Harrier 41 Electric User Manual
Page 27
1.27
ITEM NO.
DECRIPTION
PART NO.
QTY.
ITEM NO
309A 311A
41
Base Plate Motor
309019
1
1
42
Motor Flange
309024
1
1
43
Bolt - M8 x 40 Hex. Hd
09681
3
3
44
Motor Screen
309025
1
1
45
Capacitor
309039
1
1
46
Screw - No. 14 x 1.1/4” Self Tap
09670
4
4
47
Motor - 1.5 kw
309011
1
1
48
Motor Cover Mk2
309046
1
1
49
Screw - No. 14 x 1.1/2” Self Tap
09669
4
4
50
Cable Clip
70-09-109
1
1
51
Motor Cover Top
309020
1
1
52
Decal - Harrier 41 Electric
309040
1
1
53
Screw - No.8 x 1” Plastite
09528
2
2
54
Decal - Warning
309028
1
0
Decal - Warning
311012
0
1
55
Handlebar - Lower RH
309033
1
1
Inc. Insulator
56
Handlebar - Lower LH
309034
1
1
Inc. Insulator
57
Plug - Tube
320048
2
2
58
Handwheel 226013
2
2
59
Bolt - M8 x 45 Handlebar
226024
2
2
60
Cable Tie
3966
3
3
61
Switch
309026
1
0
Switch
311010
0
1
62
Screw - Ejot KA40 x 25
09719
2
2
63
Coupler Cable Assembly
309027
1
0
64
Hose Clip - Black
234029
1
1
65
Cleat
234014
1
1
66
Frame - Grassbag
305105W
1
1
67
Fabric - Grassbag
305104
1
1
68
Grassbag Assembly
305118
1
1
Inc. items 25 & 32
69
Handlebar - Upper
309036
1
1
70
Deflector
305102
1
1
71
Decal - Serial Number
N/A
1
1
72
Pin - 6.35 x 295
305103
1
1
73
Decal - Grass Blade
410064
1
1
PARTS LIST
