Mas system, Specifications, System – Harman-Kardon MAS 101 User Manual
Page 18: Loudspeakers
MAS SYSTEM
18
Specifications
System
Power output:
65 watts per channel, 20Hz – 20kHz, THD <0.07%, into 6 ohms, both channels driven
Bandwidth: 20Hz–35kHz,
–3dB
System frequency response:
20Hz–20kHz, ±0.5dB
Signal-to-noise ratio, A-weighted:
90dB (Analog inputs), 96dB (Digital inputs)
Channel separation:
≥65dB
Crosstalk between sources:
≥70dB
Line-level input sensitivity at 1kHz:
250mV RMS, ±1dB
Phono MM input sensitivity at 1kHz:
7.5mV
Loudspeakers
Low-frequency transducers:
Two 130mm honeycomb composite drivers, ported
High-frequency transducers:
Two 25mm MMD
®
domes, shielded
Nominal impedance:
8 ohms
Sensitivity (2.83V/1m):
85dB
Frequency response:
60Hz–25kHz (–3dB)
Crossover frequency:
2200Hz
FM Tuner Section
Frequency range:
87–108.0MHz
Usable sensitivity:
IHF 1.3μV/13.2dBf
Frequency response:
10Hz to 15.3kHz
Signal-to-noise ratio:
mono/stereo 68/65dB
Distortion:
mono/stereo 0.15/0.3%
Stereo separation:
35dB @ 1kHz, 100% deviation @ 65dBf
Selectivity:
±300kHz: 65dBF
Image rejection:
80dB
IF rejection:
90dB
Tuner output level:
1kHz, ±50kHz, Dev 500mV
Number of presets:
30
RDS capability:
PS (program service), RT (dynamic radio text)
Specifications
