Harman-Kardon MAS 101 - Manual (Page 12)

MAS SYSTEM
12
Operation
3. Press the Enter button to display “Alarm 1.” Use the 7/3 buttons to display “Alarm
2.” When the desired alarm is displayed, press the Enter button to set it. The
“Weekday: On” message will appear. Use the
7/3 buttons to display the Weekday
Time, Weekend On/Off, Weekend Time or Source Settings, and press the Enter button
to make a change. You may adjust the Weekday, Weekend and Source settings for
either alarm.
Weekday On/Off: Select to adjust whether Alarm 1 or Alarm 2 will sound on week-
days. Use the 7/3 buttons to turn the setting On or Off. Press the Enter or Back button
to save the change.
Weekday Time: Select to set the Alarm 1 or Alarm 2 time for weekdays. The numeric
time display will appear, with the hour setting flashing. Use the numeric keys to enter
the two-digit hour setting, and the minute setting will flash. Use the numeric keys to
enter the two-digit minute setting. Press the Enter button to advance from one field to
the next without changing it, and press the Enter or Back button to save the change.
Weekend On/Off: Select to adjust whether Alarm 1 or Alarm 2 will sound on week-
ends. Use the 7/3 buttons to turn the setting On or Off. Press the Enter or Back button
to save the change.
Weekend Time: Select to set the Alarm 1 or Alarm 2 time for weekends. The numeric
time display will appear, with the hour setting flashing. Use the numeric keys to enter
the two-digit hour setting, and the minute setting will flash. Use the numeric keys to
enter the two-digit minute setting. Press the Enter button to advance from one field to
the next without changing it, and press the Enter or Back button to save the change.
Source: Select the source that will play when Alarm 1 or Alarm 2 sounds. The week-
day and weekend alarms for each of Alarm 1 and Alarm 2 must use the same source.
If you prefer different sources for weekdays and weekends, use Alarm 1 for weekdays
only and Alarm 2 for weekends only by adjusting the Weekday On/Off and Weekend
On/Off settings appropriately.
Use the t 7/3 buttons to select one of these sources: Disc, USB A (front) or B (rear),
Radio FM, Radio DAB (available only on MAS 111) or DMP (iPod docked in The
Bridge IIIP when available). If Disc, DMP or USB A or B is selected, make sure a
CD, iPod or USB is present and contains audio materials. If no device is present,
the system will switch to FM Radio. Press the Enter or Back button to save the
change.
4. You may adjust the duration of playback and the snooze control, as well as the volume
level. These settings are global to both Alarm 1 and Alarm 2, and for both the weekday
and weekend alarms.
Alarm Timeout: With “Alarm 1” in the message display, press the 7/3 buttons until
“Timeout” appears. This setting determines how long the system will play once the
alarm sounds.
To change the Timeout setting, press the Enter button. Use the t 7/3 buttons to change
the duration of play: 10, 20, 30, 40, 50 or 60 minutes. Press the Enter or Back button
to save the change.
Snooze: With “Alarm 1” in the message display, press the 7/3 buttons until “Snooze”
appears. When the Power button or the Sleep button is pressed while the alarm is
playing, the alarm will turn off for the amount of time specified by the Snooze setting,
and will then resume.
◆ To change the Snooze setting, press the Enter button. Use the 7/3 buttons to change
how long play will be paused: 5, 10, 15, 20, 25 or 30 minutes. Press the Enter or
Back button to save the change.
Volume Level: With “Alarm 1” in the message display, press the 7/ 3 buttons until
“Level” appears. This setting only affects playback using the alarms.
◆ To change the Level setting, press the Enter button. Use the 7/3 buttons to change
the volume level within the range of – 80dB to +10dB. It is strongly recommended
that you avoid using levels higher than 0dB to preserve your hearing and to avoid
damage to the equipment. Before setting the alarm volume level, play the alarm
source to determine a comfortable volume. Press the Enter or Back button to save
the change.
S e t t i n g s
S p e a k e r S e t u p
Right
Enter Back
Left
Right
Left
>
S e t t i n g s
T i m e S e t u p > <
S e t t i n g s
A l a r m S e t u p > <
A l a r m S e t u p
A l a r m 2 <
A l a r m S e t u p
T i m e o u t < >
T i m e o u t
1 0 m i n >
S n o o z e
0 5 m i n
>
A l a r m 2 S e t u p
W e e k d a y : O n >
A l a r m 2 S e t u p
W e e k d a y T i m e
> <
A l a r m S e t u p
S n o o z e > <
A l a r m 2 S e t u p
W e e k e n d : O f f > <
A l a r m 2 S e t u p
W e e k e n d T i m e
W e e k e n d T i m e
1 0 : 0 0
A l a r m 2 S o u r c e
D i s c
> <
A l a r m 2 S e t u p
S o u r c e <
W e e k e n d A l a r m
O f f <
A l a r m S e t u p
L e v e l <
L e v e l
– 5 5 d B >
W e e k d a y T i m e
0 7 : 1 5 > <
W e e k d a y A l a r m
O n >
A l a r m S e t u p
A l a r m 1 >
A l a r m 1 S e t u p
W e e k d a y : O n >
A l a r m 1 S e t u p
W e e k d a y T i m e
> <
A l a r m 1 S e t u p
W e e k e n d : O f f > <
A l a r m 1 S e t u p
W e e k e n d T i m e
> <
> <
A l a r m 1 S e t u p
S o u r c e > <
A l a r m 1 S o u r c e
D i s c >
>
W e e k d a y A l a r m
O n >
W e e k d a y T i m e
0 7 : 1 5
Enter Back
Enter Enter or Back
Enter Enter or Back
Enter Enter or Back
Enter Enter or Back Enter Enter or Back Enter Enter or Back
Enter Enter or Back Enter Enter or Back Enter Enter or Back Enter Enter or Back
Right
Left
Right
Left
Right
Left
Right
Left
Enter Enter or Back Enter Enter or Back Enter Enter or Back Enter Enter or Back
Right
Left
Right
Left
Right
Left
Right
Left
Right
Left
Right
Left
Right
Left
W e e k e n d A l a r m
O f f <
W e e k e n d T i m e
1 0 : 0 0
Right
Right
Right
Left
Left
Left
Figure 3: Setting the Alarms
