Side panel features and descriptions, Figure 2: side panel features, Figure 2 – HP StorageWorks 7100ux User Manual
Page 15

Operations
15
HP StorageWorks 3800ux/7100ux Optical Jukebox User’s Guide
Side panel features and descriptions
Figure 2: Side panel features
■
Active bus indicator—Lit when the SCSI bus is active.
1
Active bus indicator
2
SCSI ports
3
Power cord strain relief clip
4
Product serial number label
5
Access panel and mounting screws
6
Cable access hole
7
Power switch
8
Power receptacle
3
4
5
6
8
7
2
1
