Hanns.G HX171 - Manual (Page 21)

User’s Manual
21
APPENDIX
SPECIFICATIONS
Driving system TFT Color LCD
LCD Panel Size 43.2cm(17.0")
Pixel pitch 0.264mm(H) x 0.264mm(V)
Video H-Frequency 31KHz – 80KHz
V-Frequency 56 – 75Hz
Display Colors 16.2M Colors
Max. Resolution 1280 x 1024 @75Hz
Plug & Play VESA DDC2B TM
ON Mode
≤
36W
Power Saving Mode
≤
2W
EPA ENERGY
STAR
®
OFF Mode
≤
1W
Input Connector
D-Sub 15pin
DVI-D 24pin (Dual-Input Model)
Maximum Screen Size
Hor. :337.92mm;
Ver. :270.34mm
Power Source 100~240VAC, 50±3Hz,60±3Hz
Environmental
Considerations
Operating Temp: 5° to 35°C
Storage Temp.: -20° to 60°C
Operating Humidity: 10% to 85%
Dimensions
378(W)×399(H)×207(D) mm
14.9”(W)×15.7”(H)×8.15”(D)
Weight (GW/NW)
5.0 kg / 4.0 kg
11.0 lb / 8.8 lb
*** The above specification is subject to actual product specification and is subject to
change without prior notice.
