21
PARTS LIST
Key No. Part No. Description Qty.
1 1109402-0 DISPLAY ASSEMBLY 1
2 3824801-0 HEAD STAND 1
3 PHIL. PAN HEAD SCREW NC8-32*5/16” 4
4 2033702-0 MAIN BOARD TO CONNECTION CABLE 1
5 PHIL. PAN HEAD SCREW NC6-32*1/4” 5
6 2138902-0 RIGHT CONNECTION DIGITAL BOARD 1
7 COUNTERSUNK PHIL. HEAD SCREW M4*6 14
8 3825201-0 LOAD CELL MOUNTING PLATE 4
9 1304202-0 LOAD CELL 4
10 401298 STRAIN RELIEF BUSHING SR-5L-1 2
11 RIGHT RAIL BASE 1
12 SOCKET HEAD CAP SCREW NC5/16-18*3/4” 8
13 MODEL LABEL 1
14 2034001-0 RIGHT CONN. BOARD TO LEFT CON. CABLE 1
15 PHIL. PAN HEAD SCREW NC10-24*3/8” 3
16 CENTER SECTION B 1
17 SOCKET HEAD SCREW NC1/4-20*5/8” 8
18 HINGE - SUGATSUNE SMH-83 2
19 COUNTERSUNK PHIL. HEAD SCREW M4*8 6
20 COUNTERSUNK PHIL. HEAD SCREW M4*12 6
21 400117 PANDVIT CCS19-S8-C 1
22 LOCKING TV BAR 1
23 T BAR 1
24 DELRIN SPACER 1
25 CENTER SECTION A 1
26 2267501-0 PLASTIC FOOT NC3/8" ASSEMBLY 4
27 3825801-0 LEXAN 0.5 SPACER 1
28 LEFT RAIL BASE 1
29 3824901-0 PLASTIC HANDLE 1
30 3825001-0 KNOB 1
31 3826001-0 RUNNER TEC ASSEMBLY 2
32 2138903-0 LEFT CONNECTION DIGITAL BOARD 1
33 3825901-0 MAT 2
34 420988 ADAPTER UNIT 6VDC 120VAC 1
35 411193 KEYPAD 600LB 1
36 HEAD TOP 1
37 LCD WINDOW 1
38 LCD BOARD 1
39 WN1412 CROSS HEAD SCREW K22L6 4
40 DISPLAY TO EAGLE P.C.B CABLE 1
41 WN1412 CROSS HEAD SCREW K30L6 4
42 EAGLE BOARD 1
43 HEAD BASE 1
44 PHIL. PAN HEAD SCREW NC6-32*3/8” 6
45 MODEL LABEL 1
46 3245801-0 INPUT/OUTPUT PORTS LABEL 1
47 PHIL. PAN HEAD SCREW NC4-40*1/4” 1
48 3822801-0 BATTERY COVER 1
49 400152 RUBBER O RING 1
50 2033801-0 BATTERY HOLDER 1
