Page 24

Operation

Full-OSD
A second display option is to have a full
screen report of the AVR65’s status
appear. To activate the full OSD, press the

OSD

button

three times in quick

succession. The first press will turn the
semi-OSD on, the second will turn the
semi-OSD off, and the third will bring a
full status report to the screen.

Note that the status report will vary
depending on the type of audio input
source in use. When an analog source is
in use, the first line in the display will show
which audio input is active (Figure 6).
When a digital audio source is in use,
the display will indicate if the coaxial or
optical input is active (Figure 7).

Figure 6

Figure 7

A U D I O S O U R C E : D I G I T A L

V I D E O S O U R C E : D V D

A U D I O I N P U T : O P T I C A L

T A P E M O N I T O R : O F F O N

S U R R . M O D E : D O L B Y

D I G I T A L

M U L T I R O O M : O F F O N

M A S T E R V O L U M E :

1 9 D B

A U D I O S O U R C E : D V D

V I D E O S O U R C E : D V D

A U D I O I N P U T : A N A L O G

T A P E M O N I T O R :

O F F

O N

S U R R . M O D E : P R O L O G I C

M U L T I R O O M :

O F F

O N

M A S T E R V O L U M E :

1 9 D B

AVR65 120 volt Rev (C) 10/6/98

Activating the full-OSD will also simplify
adjustments to any system parameter, as
all choices will be shown. The selected
option will appear in reversed, highlighted
video, while other choices will appear in
normal white on blue video.

The full-OSD system may be turned off
by pressing the

OSD

button

once.

Source Selection

• To select a source at any time, press
any of the

Source Selector

buttons on

the remote

or front panel

9 ) !

@ # $

• The front panel

Video 3 Inputs

may be used to connect a device such as
a video game or camcorder to your home
entertainment system on a temporary
basis.

• When an audio source is selected the
last video input used remains routed to
the

Video Outputs 1

and

Monitor Output

‡

. This permits

simultaneous viewing and listening to
different sources.

• During a listening session you may
wish to adjust the

Bass

and

Treble

controls to suit your listening tastes.

• Adjust the volume to a comfortable
level using the front panel

Volume

Control

or remote

Volume

Up/Down

buttons.

• To temporarily silence all speaker
outputs press the

Mute

button

d Û

This will cut the output to all speakers,
but it will not effect any recording or
dubbing that may be in progress. When
the system is muted the

MUTE

indicator

will light in the

Information

Display

. Press the

Mute

button

again to return to normal operation.

• For private listening, plug the

stereo phone plug from a pair of stereo
headphones into the front panel

Headphone

jack

• When a Video Input source is selected
the video signal for that input will be
routed to the

TV Monitor Video Output

jack

‡

and will be viewable on a TV mon-

itor connected to the AVR65. Make certain
that your TV is set to the proper input to
view the signal.

• To program the AVR65 for automatic
turn off, press the

Sleep

button

the remote. Each press of the button will
increase the time before shut down in the
following sequence:

The sleep time will be displayed in the
Information Display and it will count
down until the time has elapsed.

When the programmed time has elapsed
the unit will automatically turn off. Note
that the front panel display will dim to
one half brightness when the Sleep func-
tion is programmed. To cancel the Sleep
function, press the

Sleep

button

until the information display returns to
normal brightness and the Sleep
indicator numbers disappear.

min

OFF
