The FRONT panel jacks are provided as a convenience to allow you to easily connect HDMI or DVI signals
from a DVD, Set Top Box , Video Game as shown in the following examples (When connecting DVI signal it will
OUTPUT
L R DIGITAL OUTPUT
DVI to HDMI
Cable
Back of
HDTV Set-Top-Box or
DVD Player
HDMI DIGITAL
OUTPUT CAPABILITY
DVD , Set Top Box,
Video Game Console.
FRONT INPUT PANEL
DVI DIGITAL
OUTPUT CAPABILITY
DVD , Set Top Box,
Video Game Console.
need to connect the audio output into the Front Audio Input jacks) :
A) Connecting HDMI signal.
B) Connecting DVI signal.
FRONT INPUT PANEL
PUSH EJECT
PHOTO INPUT
PUSH EJECT
PHOTO INPUT
specifications.
Note : Special device cables will be
according to the own device
Connecting External Video Sources
NOTE: 1. Completely insert connection cord plugs when connecting to front panel jacks. If you do not, the played back
picture may be abnormal.
specifications.
Note : Special device cables will be
according to the own device
