8. Place the two louver rings over the globe and align the four holes in the rings with the four holes
in the globe. read two screws through to keep the holes aligned. (see figure 4)
9. Align the notch in the upper louver ring with the pull chain switch on the light kit. Align two
screws with two of the four holes in the light kit rim. (see figure 5)
10. Securely install the two threaded screws, followed by the two remaining screws. (see figure 6)
11. Restore power to the ceiling fan.
figure 4
globe
upper ring
lower ring
figure 5
notch
pull
chain
figure 6
screws
screws
screws
