Dishwasher
This unit is a tableware-cleaning dishwasher. It sprays hot water with detergent on the tableware, then flushes with clean water.
Used when opening or closing the
door. Be careful not let the door
open accidentally.
Handle
First push, on; Second push, off.
PARTS AND FUNCTIONS
Foot
Washing while Rotating.
Door seal
Filter
Separates water with residues.
Door
Exhaust outlet
Draining hose
Water inlet tube
Connected with a tap.
Hot air comes out from here in
operation.
For detail, see the follows.
Operation board
Power cable
Water inlet
Washing box
Switch
Lower sprayer
GB
KOK
Detergent Container
