Page 10
10
FRONT PANEL JACKS AND CONNECTIONS
NOTE:
Optional adapter for *Apple® Macintosh® computers. If the optional AESP model G301/U Macintosh to VGA® adapter
connector is configured and connected between Macintosh video out and the Rear Projection Television video in, the
Macintosh is forced to boot in 640 x 480/60 Hz or 800 x 600/60 Hz mode (set mode) because the operational adapter
correctly manipulates the Macintosh sense pins.
For the optional adapter to work, it s DIP switch settings should be # 2, 3, 6, 7 = ON and # 1, 4, 5, 8, 9, 10 = OFF.
See below: Example - See Switch Instructions for details.
Mode 5 = 2367 (SVGA 800 x 600/60 Hz configuration)
(VGA 640 x480/60 Hz configuration)
Composite Separate Sync
ON
DIP
1 2 3 4 5 6 7 8 9 10
ON
1
4 5
8 910
2 3
67
OFF
SW1
SW2
SW3
SW4
SW5
SW6
SW7
SW8
SW9
SW10
ON
ON
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
A/V Cable and
S-INPUT Cable
(Optional)
Back of VCR
D-SUB 15 Pin
RGB Cable
(Optional)
PC
AUDIO OUT
Back of PC
Audio Cable
(Optional)
S-VHS Video Camera Output
̇
VIDEO 3
VOL-
̇
̇
AUDIO IN
VIDEO 3/PC2
L/(MONO)
R
VIDEO
S-VIDEO
PC2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
INPUT
VOL+ CH- CH+
TV/PC EXIT
MENU
̈
SELECT
̇
VIDEO 3
VOL-
̇
̇
AUDIO IN
VIDEO 3/PC2
L/(MONO)
R
VIDEO
S-VIDEO
PC2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
INPUT
VOL+ CH- CH+
