75
TECHNICAL & CONSUMER INFORMATION
Specifications
Dimensions
Engine
Generator
EM5000is
218.0 lbs (98.9 kg)
27.9 in (709 mm)
27.2 in (692 mm)
26.5 in (672 mm)
45.5 in (1,155 mm)
31.9 in (810 mm)
EAJJ
Model
Type
Description code
Length
[Handle in up position]
Width
Height
[Handle in up position]
Dry mass [weight]
Model
Engine type
Displacement
[Bore
Stroke]
Compression ratio
Engine speed
Cooling system
Ignition system
Oil capacity
Fuel tank capacity
Spark plug
Rated voltage
Rated frequency
AC output Rated current
Rated output
Maximum output
5.0 kVA
4.5 kVA
37.5/18.8 A
60 Hz
120/240 V
W16EPR-U (DENSO)
BPR5ES (NGK)
4.23 US gal (16.0 ) 4.36 US gal (16.5 )
1.2 US qt (1.1 )
Full transistor
Forced air
2,400 3,600 rpm
8.0:1
3.23 2.52 in (82.0 64.0 mm)
20.6 cu-in (337 cm )
4-stroke, overhead valve, single cylinder
GX340K1
California type
(AC type)
Non-California type
(AN type)
]
Eco-Throttle ON
]
]
[
[
[
With battery
