4
1. Temperature Knob
2. Function Knob (functions may differ
depending on model)
3. ON/OFF Oven Control/Timer/
Toast Color Knob
4. Oven Rack
5. Slide-Out Crumb Tray
6. Broil Rack
7. Baking Pan
Parts and Features
Broil Rack
Baking Pan
When broiling, the broil
rack sits in the baking
pan as shown.
Oven Rack Positions
The oven has grooves in the side walls
that let the oven rack be placed in
different positions. Middle Rack Position
• for baking and broiling
High and Low Rack Positions
• use high rack position for broiling
and toasting
• use low rack position for baking
Pan Sizes
The following pans should fit your toaster oven. To be sure, place the pan in the
oven to check the fit before preparing the recipe.
6-cup muffin pan
8 x 4 loaf pan*
9 x 5 loaf pan*
8-inch round or square baking pan
Most 1 to 1
1 ⁄
2
quart casserole dishes
* The loaf pans will fit but do not fill more than half full.
