SECTION C: APPLY HEIGHT AND MOVING LABEL
DIRECT MOUNT & EXT. ARM
PORTABLE
201261
Eng: Dan\Tom
1st Used:
3/99
Size = 4" x 3"
Corner Radius = 3/8"
Die Cut Label
3.25 Mil Vinyl
All Temp. Permanent Adhesive
1 Mil. Polypropolyne Overlaminate
Illustrator 8.0 = EPS
Backing + 1/16 Circumference
Rolls of 500
201261 3/99
1
3
2
MOVING SYSTEM
1. While holding pole, rotate
basketball system forward
until wheels engage with
ground.
2. Move basketball system to
desired location.
3. Carefully rotate basketball
system upright.
4. Reattach ground restraint and
check system for stability.
Apply Height and Moving label on pole as shown.
13
13
DO NOT LEAVE ASSEMBLY
UNATTENDED WHEN
EMPTY; IT MAY TIP OVER.
WARNING!
