Warning – Huffy 540D User Manual
Page 12
12
ID# 21198805
10/05
Do not use
washers here on
spring return
style rims.
20
19
16
21
15
18
10
29
7.
Install backboard assembly to the pole assembly as shown. Attach backboard and
rim (16) to the extension arm (18) using bolts (20), spacers (21), washers (10, 19) and
nuts (15) as shown. Tighten completely. Attach bolt covers (29).
TWO PEOPLE REQUIRED
FOR THIS PROCEDURE.
FAILURE TO FOLLOW THIS
WARNING COULD RESULT IN
SERIOUS INJURY AND/OR
PROPERTY DAMAGE.
WARNING!
Peel protective
film from surface
of acrylic
backboard prior
to use.
NOTE:
BOARD STYLE
MAY VARY
NOTE:
