13
First time use
test-bleed 3/3/06 10:18 AM
REMOTE CONTROL sensor
Point your remote at this area when selecting
channels, adjusting volume, etc.
ቪ
INPUT- FRONT JACKS
INPUT - FRONT provide composite Video jacks for
connecting equipment with this capability ,
such as a DVD player or Camcorders .
Front Panel Controls
POWER light indicator
To turn the TV ON, press the main power
switch located on the lower right side of the
TV. A red stand-by indicator lamp located on
the lower right corner of the front bezel will
illuminate. The Plasma TV is now ready for
remote ON/OFF operation.
NOTES: 1. Your HITACHI Plasma TV will appear to be turned OFF (lights orange) if there is no video input
when INPUT : 1, 2, 3, and Front. Check the Power Light to make sure the TV is turned off or
in Stand-by mode (lights red) when not in use.
2. Remote Control can not turn ON/OFF the “MAIN POWER” of the TV.
Indicating Lamp Power Status Operating
OFF. When the main power switch is set to Off.
When the main power switch on the TV is ON.
(Stand-by)
Lights
Blue
On
TV MAIN POWER is ON with no signal input
(Power Saving) except antenna (no sync. signal).
Off
Lights
Red
OFF.
Lights
Blue
(Turning ON )
OFF.
TV MAIN POWER is ON ; but no picture is shown.
TV MAIN POWER is ON ; picture is shown.
Lights
Orange
Off
Blinking
Blue 3 times On When TV receive the IR signal once from R/C.
Indicating Lamp
R/C sensor
