SKU 35740 For technical questions, please call 1-800-444-3353. Page 8
Nut
(#23)
Power Cord
(#17)
Switch Box
(#15)
Screw
(#20)
Washer
(#21)
Lock
Washer
(#22)
Ground
Wires
Black Wire
(from Pump)
White Wire
(from Pump)
Step 3: Attach the SWITCH BOX (#15) to the TANK (#1) using two SCREWS (#20),
WASHERS (#21), LOCK WASHERS (#22), and NUTS (#23) as shown in Figure 3.
Figure 3 — Attaching the Switch Box to Tank
Step 4: When attaching the right side of the SWITCH BOX, make sure the SCREW also
secures the side of the CORD CLAMP that was left unattached in Step 3, above.
