Hotpoint FDW60 - Manual (Page 19)

19
D ISHWASHER
Fault Area Issue
Cause/How to resolve…
Tablet Not Dissolving Wherever possible the following should be positioned away from
dispenser, to ensure that they can not come into contact with the
Dispenser.
- Cutlery/Cutlery Basket
- Crockery
- Casseroles Dishes/Pans Etc.
Poor Wash Results Spray arm Obstruction
Upper
Basket
Upper
Spray
Arm
Spray wash jet
holes
- Prior to starting the programme ensure the spray wash jet holes are
not blocked and also that the spray arms can rotate freely.
With the upper basket in the lower
position, the maximum height for
plates is 26 cm. With the upper basket in the upper
position, the maximum height for
plates is increased to 31 cm.
Poor Drying Results Fast Wash Programme Selected
- There is no drying cycle on the Fast Wash Programme.
To adjust the upper basket position, follow instruction below:-
Step 1: Push the white stoppers at the front of the basket shelves outwards
and remove the basket (See fig.1 & Fig. 2).
Step 2: Push the basket runners back into the dishwasher with the stoppers
still pointing outward (See Fig.3)
Step 3: Select required position, if lower position selected top wheel
would glide into the basket runners (See Fig.4) and if upper position required
bottom wheel will be in runners (Fig.5)
)LJ )LJ )LJ )LJ )LJ
26 cm
26 cm
21 cm
31 cm
