Model SM Air Defrost | 60 Hz
Model HP
Shaded Pole PSC Motor EC Motor
115/1/60 08-30/1/60 115/1/60 08-30/1/60 115/1/60 08-30/1/60
Amps Watts Amps Watts Amps Watts Amps Watts Amps Watts Amps Watts
SM052 1/15 .1 135 1.1 135 0.9 90 0.5 90 0.9 55 0.5 55
SM076 1/15 . 270 . 270 1.8 180 1.0 180 1.8 110 1.0 110
SM090 1/15 . 270 . 270 1.8 180 1.0 180 1.8 110 1.0 110
SM102 1/15 . 270 . 270 1.8 180 1.0 180 1.8 110 1.0 110
SM108 1/15 6.3 405 3.3 405 .7 270 1.5 270 .7 165 1.5 165
SM134 1/15 6.3 405 3.3 405 .7 270 1.5 270 .7 165 1.5 165
SM156 1/15 6.3 405 3.3 405 .7 270 1.5 270 .7 165 1.5 165
SM179 1/15 8. 540 . 540 3.6 360 .0 360 3.6 220 .0 220
SM208 1/15 8. 540 . 540 3.6 360 .0 360 3.6 220 .0 220
SM249 1/15 10.5 675 5.5 675 .5 450 .5 450 .5 275 .5 275
Specifications
Model SM Air Defrost | 50 Hz
Model HP
PSC Motor EC Motor
110/1/50 0/1/50 110/1/50 0/1/50
Amps Watts Amps Watts Amps Watts Amps Watts
SM052 1/15 0.8 80 0. 80 0.9 55 0.5 55
SM076 1/15 1.7 160 0.8 160 1.8 110 1.0 110
SM090 1/15 1.7 160 0.8 160 1.8 110 1.0 110
SM102 1/15 .5 240 1. 240 1.8 110 1.0 110
SM108 1/15 .5 240 1. 240 .7 165 1.5 165
SM134 1/15 .5 240 1. 240 .7 165 1.5 165
SM156 1/15 3.3 320 1.6 320 .7 165 1.5 165
SM179 1/15 3.3 320 1.6 320 3.6 220 .0 220
SM208 1/15 3.3 320 1.6 320 3.6 220 .0 220
SM249 1/15 . 400 .0 400 .5 275 .5 275
Model SME Electric Defrost | 60 Hz
Model HP
Shaded Pole Motor PSC Motor EC Motor Heaters
08-30/1/60 08-30/1/60 08-30/1/60 08-30/1/60
Amps Watts Amps Watts Amps Watts Watts
SME040 1/15 1.1 135 0.5 90 0.5 55 5.3
SME054 1/15 . 270 1.0 180 1.0 110 8.7
SME065 1/15 . 270 1.0 180 1.0 110 8.7
SME090 1/15 3.3 405 1.5 270 1.5 165 10.5
SME130 1/15 3.3 405 1.5 270 1.5 165 15.7
SME174 1/15 . 540 .0 360 .0 220 20.9
Model SME Electric Defrost | 50 Hz
Model HP
PSC Motor EC Motor Heaters
0/1/50 0/1/50 0/1/50
Amps Watts Amps Watts Watts
SME040 1/15 0. 80 0.5 55 5.3
SME054 1/15 0.8 160 1.0 110 8.7
SME065 1/15 0.8 160 1.0 110 8.7
SME090 1/15 1. 240 1.5 165 10.5
SME130 1/15 1. 240 1.5 165 15.7
SME174 1/15 1.6 320 .0 220 20.9
NOTE: Shaded pole motors
are standard for all 60 Hz
units and PSC motors are
standard for all 50 Hz units
