9

2. HOW TO REMOVE PANELS - See Fig. 1

a) Front Panel ......... Remove the screw.

Lift up and pull toward
you.

b) Top Panel ............ Lift its front up slightly,
push away, and then lift
off.

c) Side Panel (R) ..... Remove the screw.

Pull slightly toward you,
and lift off.

d) Insulation Panel ... Lift up slightly, and pull
toward you.

3. LOCATION

WARNING

This icemaker is not intended for outdoor use. Normal operating ambient
temperature should be within +45°F to +100°F; Normal operating water
temperature should be within +45°F to +90°F. Operation of the icemaker, for
extended periods, outside of these normal temperature ranges may affect
production capacity.

For best operating results:

• Icemaker should not be located next to ovens, grills or other high heat producing

equipment.

• Location should provide a firm and level foundation for the equipment.

• Allow 6" clearance at rear, sides and top for proper air circulation and ease
of maintenance and/or service should they be required.

Fig. 1
