14
2. Position the new wall plate on the wall and pull
the labeled wires through the opening.
3. If the existing holes do not match those on the
Hunter wall plate, or if there are no existing
holes, level the wall plate and mark the wall for
two holes.
4. remove the wall plate and drill two 3/16” holes
where marked.
5. Tap the plastic anchors into the holes until they
are flush with the wall.
6. reposition the wall plate on the wall, pulling the
wires through the opening. Insert the mounting
screws through the mounting holes and into the
anchors. Verify that the thermostat is visually
level and securely tighten both screws.
InSTAllInG THE THErMOSTAT, COnT.
InSTAllInG THE WAll PlATE
