Power Output:
High-Current Capability:
Frequency Response:
Power Bandwidth:
THD/IMD:
Crosstalk
Negative Feedback:
Input Impedance:
Input Sensitivity:
Remote Trigger Voltage:
Remote Trigger Impedance:
Dimensions (H x W x D):
Weight:
Power Requirements:
5 x 100 watts @ 8 ohms
20Hz – 20kHz, <0.03% THD, All Channels Driven
5 x 150 watts @ 4 ohms
20Hz – 20kHz, <0.03% THD, All Channels Driven
± 100 Amps
<1Hz – 170kHz ± 3dB
<1Hz – >100kHz
<0.03% at rated output
< –87dBr between any two channels at
maximum output
<25dB
33K ohms
1 volt for rated output
6 – 12 volts DC (tip of plug must be “positive” ( + ))
20K ohms
17 1 ⁄ 4 x 7 1 ⁄ 2 x 15 1 ⁄ 4 inches
438 x 191 x 387 mm
47 lbs/21 kg
120VAC, 50Hz / 60Hz
950 watts, maximum
All features and specifications are subject to change without notice.
Signature 2.1 Multichannel Amplifier Specifications
