35 Heat & Glo • VRTIKL-AU • 2123-900 • 7/07
C. Flue Components List
COMPONENTS
Ceiling Support / Wall Thimble, Black 656-230
150 mm Pipe Length, Black 908B
220 mm Pipe Length, Black 907B
310 mm Pipe Length, Black 906B
600 mm Pipe Length, Black 904B
910 mm Pipe Length, Black 903B
1210 mm Pipe Length, Black 902B
280 - 370 mm Pipe Length, Black 911B
310 - 430 mm Pipe, Adjustable, Black 912B
90 degree Elbow, Black 990B
150 mm Pipe SL-06D
220 mm Pipe SL-09D
310 mm Pipe SL-12D
600 mm Pipe SL-24D
910 mm Pipe SL-36D
1210 mm Pipe SL-48D
90 degree Elbow SL-90D
Storm Collar SL-SCD
Ceiling Firestop SL-FCD
Wall Firestop SL-FWD
Pipe Support Strap SL-PSD
Decorative Radius Cover DRC-RADIUS
Slim Line Heat Shield HTI-DV-WT
TERMINATION KITS
Trapezoid Termination Kit 197 mm - 280 mm, 2 Firestops SLK-01TRD
Vertical Termination Cap - High Wind SLK-991DA
