P
E R F O R M A N C E
S
P E C I F I C A T I O N S
P7000
Power Rating:
FTC (20Hz-20kHz, <0.1% THD)
EIA (1kHz, 0.1% THD)
350 wpc into 8
Ω
375 wpc into 8
Ω
500 wpc into 4
Ω
*
525 wpc into 4
Ω
*
1000 wpc into 8
Ω
*
1050 wpc into 8
Ω
*
*Continuous sine wave power limited by current rating of line fuse.
Signal-to-Noise:
100dB below rated output from 20Hz to 20kHz
Frequency Response:
±
0.1dB, 20Hz to 20kHz
+0/–3dB, 0.2Hz to 100kHz
Slew Rate:
100 V/
µ
s
Input Impedance:
47,000
Ω
per phase
Input Sensitivity Range for rated output power:
Unbalanced: 1.7V-9.5V RMS (8
Ω
), 1.4V-8V RMS (4
Ω
)
Balanced:
0.85V-4.75 RMS (8
Ω
), 0.7V-4V RMS (4
Ω
)
Gain:
+15dB min. / +30 max.
CMRR:
–75dB at 1kHz
Damping Factor:
600 (to 1kHz); 200 (to 10kHz); 25 (to 100kHz)
Power Consumption: 275 VA quiescent.
1440 VA with both channels driven at 350 watts at 8
Ω
, 1800 VA maximum.
Controls & Switches: Front Panel: Power switch, Normal/Bridged mode switch, level controls
Rear Panel: Chassis/Float ground switch, Stereo/Bi-amp selector switch
Crossover:
Variable high-pass, low-pass and bandpass; 100Hz as supplied
Indicators:
Power lamp, Clip, Short, Thermal, Signal LEDs
Connectors:
Input:
2-way XLR and 1/4" Tip Ring Sleeve
Output: 5-way binding posts spaced for dual banana plugs
Power: IEC 320
Dimensions:
19"W x 12
7
⁄
8
"D x 3
1
⁄
2
"H plus 1
1
⁄
8
" for handles, includes rear supports
(48.3cm x 32.7cm x 8.3cm plus 2.875cm for handles, includes rear supports)
Net Weight:
40 lbs. (18.18kg)
