Service parts, Isle royale wood stove – Hearth and Home Technologies 823-0170 User Manual
Page 28

R
Page 28
September 1, 2008
Isle Royale Wood Stove
250-5763C
Andiron Brackets, Pair
832-3610
Andirons with Brackets
844-8980
Ash Removal System Handle Assembly
472-5060
Ash Box Hinge
434-0310
Ash Lip Must specify color.
29125
Ash Pan
434-0330
Ash Removal Door
434-0300
11
Ash Removal Grate
834-4100
Baffle Assembly
SRV434-5010
9
Baffle Back Plate
434-0370
Baffle Control Cam
434-0080
Baffle Repair Kit
834-4040
Baffle, Cast
434-0110
Baffle, Lever
434-0100
Blower Assembly
831-1701
Blower Cord with Speed Control
821-0110
Blower Cover Plate, Rear Vent
434-7060
Blower Only, Service
812-4900
Brick Retainer
434-0460
1
Brick Set
834-3860
Bricks with Hole (2)
SRV434-0620
Brick, Single, Uncut, Pumice
832-0550
20
Cam Latch
32084
Component Pack, Matte Black
(Includes Owner’s Manual; Griddle Handle; Fiber Handle; Warranty Card; Touch-up Paint)
MBK: 434-5160
PMH: 434-5220
Control System Control Rod
31940
Door Hinge, Left
434-0470
Door Hinge, Right
434-0480
13
Door, Left, Matte Black
844-9640MBK
13
Door, Left, Porcelain (Must specify color).
844-9650POR
14
Door, Right, Matte Black
844-9680MBK
14
Door, Right, Porcelain (Must specify color).
844-9690POR
Fiberboard, Baffle
434-0650
Fiberboard, Rear
434-0660
4
Flue Shield, Bottom
434-0680
3
Flue Shield, Top
434-0670
5
Flue Transition Assembly
7006-019
Gasket, Glass Rope, 1/4”, 10 ft.
834-1460
Gasket, Rope, Door
834-4170
16
Glass Assembly
434-5230
Item
#
Part Description
Alphabetical Order
SKU
IMPORTANT:
THIS IS DATED INFORMATION.
The most current information is located on the Quadra-Fire web site
at
www.quadrafire.com. When ordering, supply serial and model numbers to ensure correct part.
Service Parts
