Page 93
91
OPTIONAL PARTS
Hanger Kit
TORQUE:
HANGER
GENERATOR
SIDE
HANGER BRACKET (2)
8
16 mm FLANGE BOLT (4)
HANGER
FUEL TANK
RIB
Position the hanger at the generator’s balance point as shown below.
Fit the end tabs of the hanger through the bracket slots, and bolt the
brackets to the hanger and tighten securely.
17
22 lbf·ft (24
29 N·m , 2.4
3.0 kgf·m)
1.
2.
05/04/25 09:50:02 31Z11600_092
