2
P/N 211972B
06/03
WARRANTY CARD:
Please remember to complete your product
registration form either
on-line at:
www.huffysports.com/warrantycard
or mail-in the enclosed postcard.
Item
Qty.
Part No.
Description
1
1
900149
Top Pole Section, Black
2
1
904811
Middle Pole Section, Black
3
1
903407
Bottom Pole Section, Black
4
1
200188
Rod, 3/8 x 5-1/4 Long Zinc
5
1
202822
Eyebolt, 3/8–16 x 3-3/4 Long
6
1
200117
Tank
7
1
203124
Stake, Tie Down
8
4
203063
Lock Nut, Nylon Insert, 3/8–16
9
2
906410
Struts, Base
10
1
202662
Bolt, 5/16-18 x 4-1/2 Long
11
12
203218
Washer, Flat, 5/16 x 7/8 O.D.
12
1
203220
Lock Nut, Nylon Insert, 5/16-18
13
1
200516
Vinyl, Bolt Cover, 5/16
14
2
203798
Bolt, Hex Flange, 5/16-18 x 1-1/2 Long
15
20
203100
Lock Nut, Whiz, 5/16-18
16
1
203223
Bolt,Carriage 5/16-18 X 1.00” Long
17
2
226401
Wheel 4” Diameter
18
1
200123
Upper Pivot Bracket
19
1
200512
Bolt, Hex Head,3/8-16 x 3-1/2 Long
20
5*
203232
Washer, 3/8 I.D. x 3/4 O.D.
21
1
206252
Bolt, Hex Head, 3/8-16 x 1 Long
22
1
206948
Lower Pivot Bracket
23
1
203330
Bolt, Hex Head, 3\8-16 x 4-1/2 Long
24
2
200122
Hinge Tubes
25
2
900223
Wheel Bracket
26
4
203103
Bolt, Carriage, 5/16-18 x 2 Long
27
2
226403
Wheel 6” Diameter
28
2
206940
Axle, .461 O.D. x 21 Long
29
4
206938
Push Caps
30
1
206956
Disc, Plastic, 5” O.D. x .0625 Thick
31
1
204839
Tinnerman Nut
32
1
904816
Inner Channel
33
1
904815
Outer Channel
34
1
204813
Handle, Height Adjustment
35
2
203217
Bolt, Carriage, 5/16-18 x 1-1/2 Long
36
1
203679
Bolt, Hex Head, 3/8-16 x 2 Long
37
3
201124
Lock Nut, Hex, 3/8-16
38
1
204814
Trigger, Height Adjustment
39
1
203589
Bolt, Hex Head, 5/16-18 x 1-1/4 Long
40
1
201125
Ratchet Spring
41
1
211257
Label, Accuheight
Item
Qty.
Part No.
Description
42
4
265601
Bolt, Carriage, 5/16-14 x 3-1/2 Long
43
2
204840
Pin, 3 x 3/8
44
2
204841
Spring, Silver
45
1
204819
Bracket, Pole Mount
46
2
203053
Bolt, Carriage, 5/16-18 x 4 Long
47
1
206990
Reinforcement Bracket
48
1
204811
Spring Cover, Handle Left Side
49
1
204812
Spring Cover, Handle Right Side
50
1
206263
Bolt, Carriage, 5/16-18 x 3 Long
51
2 200874
Spacer,
Metal
52
2
900103
Bracket Backboard Support
53
2
206360
Bolt, Hex Head, 3/8-16 x 2-5/8 Long
54
1
200118
Front Cover
55
12*
201219
Smart Clip, Net Holder
56
2
904821
Elevator Tube, Lower (Long)
57
6
204847
Bolt, Hex Head, 1/2-13 x 9-1/2 Long
58
7
206340
Lock Nut, Hex Head, 1/2-13
59
4
201682
Spacer, .56 I.D. x .683 O.D. x 1.88 Long
60
4
205528
Bolt, Hex Flange, 5/16-18 x 1 Long
61
1
201568
Anchor Strap
62
1
206219
Cap, Tank-Black
63
2
904807
Elevator Tubes, Upper (Short)
64
1
207103
Pole Cap
65
1
201139
Bolt, Hex Head, 1/2-13 x 4-1/2 Long
66
2
201654
Triangle Plate
67
8
202862
Spacer, Plastic, 1/2 I.D. x 1-1/4 Long
68
2
204838
Spring
69
1
Rim
70
1
204290
Net
71
1
211249
Label, Height and Moving
*You may have extra parts with this model.
PARTS LIST - See Hardware Identifier
WARNING: IF YOUR SYSTEM IS EQUIPPED WITH AN ACRYLIC
BACKBOARD, EXAMINE BACKBOARD FOR ANY DAMAGE THAT MAY
HAVE OCCURRED DURING SHIPMENT. CRACKS IN THE BACKBOARD
COULD RESULT IN SUDDEN BREAKAGE. IF BACKBOARD IS DAMAGED
IN ANY WAY PRIOR TO OR AFTER ASSEMBLY, CALL TOLL-FREE
NUMBER FOR FREE REPLACEMENT:
U.S. 1-800-558-5234; CANADA: 1-800-284-8339; http://www.huffysports.com
