HSM Securio B24 - Manual (Page 13)

0804 13
english
8 Technical data
Cutting type Strip cut Cross cut
Cut size (mm) 5.8 3.9 4.5 x 30 1.9 x 15
Security level DIN 32757 - 1 2 2 3 4
Cutting capacity (sheets), A4 70 g/m 2
80 g/m 2
28 - 30
25 - 27 22 - 24
19 - 21 17 - 19
14 - 16 11 - 13
9 - 11
Weight 18 kg 20.5 kg
Cutting speed 65 mm/s
Intake width 240 mm
Power supply
Power consumption
with max. number of sheets
230 V, 50 Hz 100 V, 50/60 Hz – 115 V, 60 Hz
500 W 580 W
Size W x D x H (mm) 395 x 317 x 605
Shredded material container volume 34 litres
Noise emission (idle running / under load) 56 dB(A) / 59 - 63 dB(A)
EC declaration of conformity
Machinery directive 98 / 37 / EC
EMC directive 89 / 336 / EEC
Low voltage directive 73 / 23 / EEC
The manufacturer – HSM GmbH + Co. KG, Bahnhofstrasse 115, D-88682 Salem, Germany – hereby declares that the
document shredder SECURIO B24 complies with the EC directives listed above, including all modifi cations that apply.
Applied standards and technical specifi cations:
• EN 55014-1:2000 + A1:2001 + A2:2002
• EN 61000-4-4:1995 + A1:2001 + A2:2001
• EN 55014-2:1997 + A1:2001 • EN 61000-4-5:1995 + A1:2001
• EN 61000-3-2:2000 • EN 61000-4-6:1996 + A1:2001
• EN 61000-3-3:1995 + A1:2001 • EN 61000-4-11:1994 + A1:2001
• EN 61000-4-2:1995 + A1:1998 + A2:2001 • EN 60950-1:2006
• EN 294:1992
Salem, 02.01.2007
Rolf
Gasteier - Technical Director
The machine type was tested for compliance with the requirements of the EC Machinery Directive by the test and cer-
tifi cation board of the Technical Administation Committee, c/o Verwaltungs-Berufsgenossenschaft, Deelbögenkamp 4,
D-22297 Hamburg, Germany. This test centre is responsible according to Appendix V of the EC Machinery Directive.
