The wires in the mains supply lead are coloured in accordance with

the following code:

Green and Yellow

- Earth

Blue

- Neutral

Brown –

Live

The connection must be made as follows:
The wire coloured Green and Yellow must be connected to the
terminal marked ‘E’ or the earth symbol

A or coloured green or green and yellow.

The wire coloured Blue must be connected to the terminal marked
‘N’ or coloured blue or black.
The wire coloured Brown must be connected to the terminal

marked ‘L’ or coloured

brown or red.

NOTE: The terminals marked ‘SUPPLY’ are for the mains supply
wires and the terminations marked ‘LOAD’ are for the appliance
wires. The electrical outlet is to be positioned in an easily
accessible position adjacent to the appliance. In the event that it is
necessary to replace the mains lead, the replacement must conform
to the specification listed in the Technical Data ensuring the correct
colour code connection and that all screws are tightened

sufficiently.
