3 05/06 ID# M8000
PARTS LIST - See Hardware Identifier
Item Qty. Part No. Description
1 1 579800 Warning Label
FR579800 Warning Label
2 4 203113 Bolt, Hex Flange, 5/16-18 x 2.5 Long
3 2 203038 Bolt, Carriage, 5/16-18 x 2.75 Long
4 6 203309 Washer, 1” O.D.
5 6* 203100 Nut, Hex Flange, 5/16-18
6 1 Rim
7 1 Net
8 1 Backboard
* YOU MAY HAVE EXTRA PARTS WITH THIS MODEL.
#2 (4)
#5 (6)*
#4 (6)
#3 (2)
#6 (1)
#8 (1)
#7 (1)
Owner must ensure that all players know and follow these rules
for safe operation of the system.
WARNING
• DO NOT HANG on the rim or any part of the system including
backboard, support braces or net.
• During play, especially when performing dunk type activities,
keep player's face away from the backboard, rim and net.
Serious injury could occur if teeth/face come in contact with
backboard, rim or net.
• During play, do not wear jewelry (rings, watches, necklaces,
etc.). Objects may entangle in net.
• Check system before each use for loose hardware, excessive
wear and signs corrosion and repair before use.
• Never play on damaged equipment.
• See instruction manual for proper installation and
maintenance.
Read and understand warnings listed
below before using this product.
Failure to follow these warnings may
result in serious injury and/or property
damage.
ID#: 579800 05/05
In the U.S.: 1-888-713-5488 In the U.S.: 1-800-558-5234
In Canada: 1-800-284-8339
In the U.S.: 1-800-334-9111 In the U.S.: 1-800-558-5234
In Canada: 1-800-284-8339
#1 (1)
HARDWARE IDENTIFIER
