Assembly diagram – Harbor Freight Tools 39213 User Manual
Page 5
Page 5
SKU 39213
For technical questions, please call 1-800-444-3353.
note: Make sure that the rear
lip of each Shelf can slip into the
tabs located on the sides of the
Back Panel (8).
rear lip of shelf
Figure 5
10. Each Shelf (#10) sits in the tabs on the Back Panel (8) and the tabs on the Side
Panels (7, 16) - see Figure 5.
asseMbly diagraM
17
reV 01i, 02j, 04c, 07e
