Vacuum in any direction until the area 5.
is cleaned of dirt, debris, or liquid.
When finished, release the Power
6.
Switch (5) to turn off the Auto Vacu-
um. Then unplug the tool from the
vehicle’s cigarette lighter/accessories
outlet.
(See Figure A.)
Before storing, thoroughly clean the
7.
Collector (2), Filter Support (8), Filter
(9), and Impeller area of all dirt, de-
bris, and liquid. To do so:
Press the Collector Release Button a.
(3) to remove the Collector (2).
Remove the Filter (9) from the Filter
b.
Support (8).
Wash the Collector (2), Filter Sup-
c.
port (8), and Filter (9) with clean,
soapy water. Rinse the filter thor-
oughly. Then allow to dry.
Use a soft brush or compressed air
d.
to clean out the Impeller area.
Reassemble the Auto Vacuum and
e.
store it in a clean, dry, safe location
out of reach of children and other
unauthorized persons.
(See Figure B.)
MAinTEnAnCE AnD
SERViCing
Procedures not specifically
explained in this manual
must be performed only by a
qualified technician.
TO pREVEnT
SERiOUS injURY
FROM ACCiDEnTAL
OpERATiOn:
Turn the power Switch (5) of
the Auto Vacuum to its “OFF”
position and unplug the tool
from the vehicle’s cigarette
lighter/accessories outlet
before performing any
inspection, maintenance, or
cleaning procedures.
TO pREVEnT SERiOUS
injURY FROM TOOL
FAiLURE:
Do not use damaged
equipment. if abnormal noise
or vibration occurs, have the
problem corrected before
further use.
FigURE A
MOTOR
(1) COLLECTOR
(2)
pOWER-On LighT
(4)
pOWER SWiTCh
(5)
COLLECTOR
RELEASE
BUTTOn
(3)
LARgE
CREViSE
nOZZLE
(6)
SMALL
CREViSE
nOZZLE
(10)
LiQUiD
piCK-Up
nOZZLE
(7)
12 VOLT
pOWER
pLUg
(11)
FigURE B
COnTAinER RELEASE BUTTOn
(3)
FiLTER
(9)
FiLTER
SUppORT
(8)
COLLECTOR
(2)
iMpELLER
