MLC 206 Series
sPeCiFiCations
ControL / reMote — ControLLer
Serial control port . . . . . . . . . . . . . . . RS-232, 9-pin female D connector
Baud rate and protocol . . . . . . . . . 9600, 8-bit, 1 stop bit, no parity
Serial control
pin configurations . . . . . . . . . . . . . . . 2 = TX, 3 = RX, 5 = GND
Slave switcher control port .. . . (1) 3.5 mm direct insertion captive screw connector, 4 pole
Program control . . . . . . . . . . . . . . . . . Extron’s control/configuration program for Windows ®
Extron’s Simple Instruction Set (SIS ™ )
ControL — rooM reLays
Number / Type . . . . . . . . . . . . . . . . . . . 3 momentary or latching (configurable via control software)
Connectors . . . . . . . . . . . . . . . . . . . . . . . (1) 3.5 mm direct insertion captive screw connector, 6 pole
Contact rating . . . . . . . . . . . . . . . . . . . . 24 V, 1 A
ControL — ProjeCtor / sourCe
Display / Source control port
(IR)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (1) 3.5 mm direct insertion captive screw connector, 5 pole
Display / Source control port
(RS-232)
. . . . . . . . . . . . . . . . . . . . . . . . . . . (1) 3.5 mm direct insertion captive screw connector, 5 pole
IR learning frequencies . . . . . . . . 30 kHz to 62 kHz
IR learning distance . . . . . . . . . . . . 4" (10 cm) to 14" (36 cm) from the MLC’s faceplate
GeneraL
Power .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . Supplied by an optional MediaLink Switcher (MLS) or the included
external power supply
External power supply . . . . . . . . . 100 VAC to 240 VAC, 50/60 Hz, external, autoswitchable;
to 12 VDC, 1 A, regulated
Power input requirements . . . . . 12 VDC, 0.38 A
Temperature / Humidity . . . . . . . . Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Rack mount . . . . . . . . . . . . . . . . . . . . . . Yes, with optional MLM-RAAP rack mounting kit; also furniture
or wall-mountable
Enclosure type . . . . . . . . . . . . . . . . . . . Metal
Enclosure dimensions
Faceplate
MLC 206
.. . . . . . . . . . . . . . . . . . . . . . . . . . 4.5" H x 6.4" W x 0.1" D (11.4 cm H x 16.3 cm W x 0.3 cm D) (3 gang)
MLC 206 L . . . . . . . . . . . . . . . . . . . . . . . . 3.2" H x 6.5" W x 0.1" D (8.1 cm H x 16.5 cm W x 0.3 cm D)
MLC 206 EC . . . . . . . . . . . . . . . . . . . . . . . 3.2" H x 6.3" W x 0.1" D (8.1 cm H x 16.0 cm W x 0.3 cm D)
MLC 206 AAP EC . . . . . . . . . . . . . . . . . 3.2" H x 9.8" W x 0.1" D (8.1 cm H x 24.9 cm W x 0.3 cm D)
MLC 206 AAP . . . . . . . . . . . . . . . . . . . . . 4.5" H x 10.1" W x 0.1" D (11.4 cm H x 25.7 cm W x 0.3 cm D) (5 gang)
Controller (all models) . . . . . . . . . . . . 2.75" H x 5.25" W x 1.2" D (fits in a 3 gang box)
(7.0 cm H x 13.3 cm W x 3.1 cm D) (Depth excludes connectors and knobs.
Allow at least 1.75" depth within the wall or furniture.)
Product weight
MLC 206
.. . . . . . . . . . . . . . . . . . . . . . . . . . 1.7 lbs (0.8 kg)
MLC 206 L, MLC 206 EC . . . . . . . . 0.7 lbs (0.3 kg)
MLC 206 AAP EC . . . . . . . . . . . . . . . . . 0.7 lbs (0.3 kg)
MLC 206 AAP . . . . . . . . . . . . . . . . . . . . . 0.8 lbs (0.4 kg)
Shipping weight (all models) . . . 6 lbs (3 kg)
Vibration . . . . . . . . . . . . . . . . . . . . . . . . . . ISTA 1A in carton (International Safe Transit Association)
Listings . . . . . . . . . . . . . . . . . . . . . . . . . . . . UL, CUL
Compliances . . . . . . . . . . . . . . . . . . . . . CE, FCC Class A, VCCI, AS / NZS, ICES
MTBF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30,000 hours
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 3 years parts and labor
NOTE: All nominal levels are at ±10%. Specifications are subject to change without notice.
M e d i a L i n k ™ c o n t r o L L e r s
MLC 206 Series Accessories
inCLuded aCCessories ModeL desCriPtion PaGe Part #
EPS 1210 B Extron Desktop Power Supply - 12VDC, 2A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 694 70-055-01
UC50' (50' / 15 m) Universal Projector Control Cable 50' (15.2 m) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 419 26-518-01
IR Emitter and Shield Kit IR Emitter Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 416 70-283-01
oPtionaL aCCessories ModeL desCriPtion PaGe Part #
IPL T S2 Two Serial Port IP Link ® Ethernet Control Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 474 60-544-81
IPL T S4 Four Serial Port IP Link ® Ethernet Control Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 474 60-544-83
MLC PW/RS-232/VC-35' One Power, Switcher Communications and MPA Volume Control Cable -
Plenum, 35' (10.6 m) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 419 26-626-35
IRCM-DV+ Dual-Function DVD and VCR IR Control Module - Quad Space AAP . . . . . . . . . . . . . . page 393 70-220-02
MLA-Remote Handheld IR Remote Control For the MLC 206 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . n/a 70-154-01
MLS 304MA Four Input MediaLink ™ Switcher with Mono Audio Amplifier . . . . . . . . . . . . . . . . . . . . . . page 435 60-550-01
MLS 406SA Six Input MediaLink ™ Switcher with Stereo Audio Amplifier . . . . . . . . . . . . . . . . . . . . . . . page 439 60-560-03
MLS 506SA Six Input MediaLink ™ Switcher with Stereo Audio Amplifier . . . . . . . . . . . . . . . . . . . . . . . page 442 60-386-04
MPA 122 22 Watt Two Channel Integrated MPA - Mini Power Amplifier . . . . . . . . . . . . . . . . . . . . page 658 60-668-01
MPA 181T 70 Volt 18 Watt Mono Integrated MPA - Mini Power Amplifier . . . . . . . . . . . . . . . . . . . . page 659 60-747-01
MLM 206 L Replacement Lectern Mounting Kit for the MLC 206 L . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 406 60-387-02
UCM RAAP Universal Controller Mounting Rack Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 410 70-344-02
SMB 103 Three-Gang Surface Mounting Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 824 60-641-02
