MLC 206 Series
MLC 206
MediaLink ™ Controllers
unique Features
• Three-gang faceplate
• MR 300 Mud Ring included
MLC 206 AAP
MediaLink ™ Controller with AAP Opening
unique Features
• Five-gang faceplate
• Opening for up to four single space AAP - Architectural Adapter Plates;
AAPs sold separately
• MR 500 Mud Ring included
M e d i a L i n k ™ c o n t r o L L e r s
ModeL
Version desCriPtion Part #
MLC 206 Black . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-385-02
MLC 206 White . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-385-03
MLC 206 RAL9010 White . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-385-05
ModeL Version desCriPtion Part #
MLC 206 AAP Black . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-460-02
MLC 206 AAP White . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-460-03
MLC 206 AAP RAL9010 White . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-460-05
